Say I am debugging an #ethernet project on the #ice40 #fpga of pico-ice board. I want to know the contents of some registers down in my design (which destination MAC address my #hardware tried to transmit). I don't want to use manufacturer specific ILAs and don't want to hand route a bunch of debug signals to my top level for external #debug equipment I don't have.

In PipelineC just assign to a globally visible #UART debug probe wire:
https://github.com/JulianKemmerer/PipelineC/wiki/Example:-Debug-Probes

Finally got around to connecting my #olimex #ice40 development board to power again, and getting a bit stream programmed onto it.
(I really haven't played enough with it)

"Back in the day" I'm sure I used a raspberry pi for the programming.

This time I tried using a dirt cheap #ch341a for the programming, its a bit on the slow side, especially when programming all 2MB of SPI flash.
Probably should limit the number of bytes to be programmed and/or switch to one of my #ch347 boards

Not having #AMD #Xilinx #Vivado #Chipscope based live #hardware debug for the #picoice #Lattice #ice40 #FPGA was a little annoying

so I am hoping to revive the small pipelinec project that was sorta a build your own chipscope attempt and demo that on the pico ice

Yay those cheap #hardware #ethernet phy #pmod -LIKE things work with the pico-ice #ice40 #FPGA . Thanks for your help with RMII interface @dutracgi ! #embedded #HDL #RTL #Verilog #VHDL #HLS https://github.com/JulianKemmerer/PipelineC/blob/master/examples/pico-ice/ice_makefile_pipelinec/ethernet_top.c

Come learn some PipelineC #HDL basics featuring the pico-ice dev board from tinyVision.ai! It has a Lattice Semiconductor @latticesemi #ice40 #FPGA and @Raspberrypi. This intro talk will cover #LED, #UART, and #VGA projects using OSS CAD Suite tools. #hardware #RTL #Verilog #VHDL #HLS

In the mood for the littlest bit of #FPGA #GameDev? Check out this pico-ice based #pong demo. Just need #VGA #pmod and #UART connected to host PC. #HDL #hardware #RTL #Verilog #VHDL #HLS #lattice #ice40 https://github.com/JulianKemmerer/PipelineC/blob/master/examples/pico-ice/ice_makefile_pipelinec/pong_top.c

https://www.reddit.com/r/FPGA/comments/1hvtgn9/fpga_developers_forum_2025_call_for_abstracts/

A Curated Directory of Awesome Cologne Chips' GateMate FPGA Links.

https://github.com/PythonLinks/awesome-gatemate

The iCEBreaker FPGA dev board V1.1 is available in the US store right now! Get them while the inventory lasts. The new version features an RGB LED, additional PSRAM chip, USB-C connector, populated “ears”, as well as length matched Pmod signal connections! https://1bitsquared.com/products/icebreaker #opensource #fpga #ice40 #electronics #hacking #openFPGA

Have been super pleased with the #ice40 #FPGA and #raspberrypi board that https://pico-ice.tinyvision.ai/ sent me to experiment with. Many thanks and I look forward to putting together a talk for intro users getting started with #PipelineC and boards like the pico-ice #HDL #Verilog #VHDL #hardware #embedded

ICE-V Dual and ICE-V Dual Fermatta

These cpus have two cores which share an ALU and control structures. On calls and jumps usually RISC-V computation pauses while the core loads the next instruction and decodes it. By alternating between the two cores, this problem is avoided. And many applications can easily be split into twoth reads sharing the same memory.

By @sylefeb

https://github.com/PythonLinks/risc-v-shoot-out

Easily Build This IMU Array Sandbox https://hackaday.com/2024/10/02/easily-build-this-imu-array-sandbox/ #PeripheralsHacks #imuarray #iCE40 #IMU

Easily Build This IMU Array Sandbox - These days we’re used to our devices containing an inertial measurement unit (IMU)... - https://hackaday.com/2024/10/02/easily-build-this-imu-array-sandbox/ #peripheralshacks #imuarray #ice40 #imu

Comparing x86 and 68000 in an FPGA - [Michael Kohn] started programming on the Motorola 68000 architecture and then, fo... - https://hackaday.com/2024/06/07/comparing-x86-and-68000-in-an-fpga/ #retrocomputing #computerhacks #risc-v #ice40 #fpga #x86

#Lattice's IceCube2 software seems to be free no longer:

https://www.latticestore.com/products/tabid/417/searchid/1/searchvalue/lsc-sw-icecube2/default.aspx

The pricing is ridiculous. $471.31 for the initial license, $353.15 for every year after that.

Here are the instructions for using #e4thcom with #mecrisp on the #picoIce. #Ice40 #fpga #forth
https://mecrisp-ice.readthedocs.io/en/latest/e4thcom.html

#PBC layout question for anyone who knows more than I do about the subject (essentially everyone)...

Is it ok to put decoupling caps under the #iCE40 package (like the 3 red ones in the image) or am I better off keeping them on the same side as the IC (like the blue ones)? I only have 2 layers to play with and lots of routing on one (still to do on blue), so plan to use the other as (mostly) ground plane and power anyway.

I'm asking before I do the tedious routing ;)
